ڤ Smartline UV Detector 2600          Compact Reliability!

With Smartline UV detector 2600 every thing is possible.


The Smartline UV detector 2600 is a completely new multi wavelength spectrophotometer that is based on diode array technology. The instrument unites the advantageous and the price of outstanding 4-channel spectrophotometer with the quality of diode array detection system. The result is a UV detector with unique performance and flexibility in the new compact KNAUER Smartline design.

The Smartline UV Detector 2600 can simultaneously measure at up to four freely programmable detection channels with high sensitivity and continuously record spectra in a selectable scan range. The signals of the four channels are additionally distributed on the four analog outputs.

The flow cell is behind the front panel, on which the display and touchpad are integrated. It is well protected from outside influences, yet made easily accessible. The current KNAUER flow cells can be used in the Smartline UV detector 2600.

The entire optical unit can be removed from the front of the detector, making the lamp exchange easy since removing the housing is not necessary. Due to the fact that the instrument now has practically no moving parts; it requires very little maintenance and is highly robust.

The Smartline UV Detector 2600 together with KNAUER ChromGate® or EuroChrom® Software enables many functions that are typical of diode array detector including multi-wavelength operation, 2-D and 3-D chromatograms, peak purity, spectra libraries, and more. In addition, control is possible through the remote control connection, the open communication protocol, or the touchpad (stand alone operation).


Technical data



Detector Type: diode array spectrophotometer

Number of Diodes: 256 (1.25 nm/ diode)

Wavelength Range: 190- 510 nm/ 4 (data recording)

Spectra Scan: On-flow, max. 10 scans per second

Lamp: deuterium

Bandwidth: 4-25 nm (selectable)

Time Constant: 0.1/ 0.2/ 0.5/ 1.0/ 2.0/ 5.0/ 10.0 s

Analog Outputs (Integrator): 4 x +/- 1 V (scalable), 20-bit

Control: RS-232, remote control strip, touchpad

GLP Report: detailed, including lamp operation time, lamp ignitions

Wavelength Verification: automatic via internal holmium oxide filter

Power Supply: 90- 260 V, 47- 63 Hz



All flow cells mentioned below are also available in PEEK (except models with 10 mm path length, Ľ” connectors, and micro flow cells). A version with fiber optics connectors is available for all flow cells (except micro flow cells).






Ordering Information :
Article No.Description
A5200Smartline UV Detector 2600, flow cell excluded


Ordering Information :
Article No.Description
A4061Analytical Flow Cell 10mm, 10 µl, stainless steel
A4042Analytical Flow Cell 3mm, 2µl, stainless steel


Ordering Information :
Article No.Description
A4069Preparative Flow Cell 0.5 mm, stainless steel
A4066Preparative Flow Cell 0.5/ 1.25/ 2 mm, stainless steel, 1/8”
A4068Preparative Flow Cell 0.5/ 1.25/ 2 mm, stainless steel, 1/4”


Ordering Information :
Article No.Description
A4097Capillary Electrophoresis Cell, 1mm, stainless steel, 280 µm
